Description
Stovax Chesterfield 5 Wood Burning Stoves & Multi-fuel Stoves
Perfectly proportioned, the Chesterfield 5 wood burning and multi-fuel stove is a great fit for fireplaces or freestanding against a wall. Designed around triple airflow combustion systems, these elegant convector stoves deliver exceptional heating performance whether you choose a dedicated wood burning or multi-fuel version. Both versions feature the range’s convector design to reduce distance to combustibles and enhance heating capability. The Chesterfield 5 is an Ecodesign Plus stove, meeting and exceeding Ecodesign air quality standards, and is exempt from DEFRA Smoke Control Areas. This wood burning and multi-fuel stove is available in a wider format: the Chesterfield 5 Wide. The Chesterfield 5 is also available in gas and electric models.
Key Features
- High Efficiency: Woodburning: 77.6% / Multi-fuel: 79.5%
- Energy Efficiency Class: Woodburning: A / Multi-fuel: A+
- Nominal heat output and range: 5kW (2.5-7kW)
- Ecodesign Plus
- Convector Stove
- Cleanburn & Airwash
- DEFRA Exempt for Smoke Control Areas
- Optional Longer Legs
- Optional Dedicated External Air Kit
- 12mm hearth compatible
- Flue outlet: 5 top or rear
- Maximum Log Length: 330mm
Specifications
| Model | Width | Height | Depth | Flue Diameter | Energy Rating |
|---|---|---|---|---|---|
| Chesterfield 5 Wood | 472mm | Short Legs: 614mm Long Legs: 660mm |
397mm | 128mm | A |
| Chesterfield 5 Multi-fuel | 472mm | Short Legs: 614mm Long Legs: 660mm |
397mm | 128mm | A+ |
Dimension Diagram
| Model | A | B | C | D | E | F | G | H | I | J* | K | L | M | N ø |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Chesterfield 5 | 585 | 512 | 329 | 424 | 111 | 500 | 286 | 396 | 596 | 596 | 347 | 300 | 256 | 128 |
| Chesterfield 5 Wide | 641 | 575 | 370 | 490 | 111 | 563 | 329 | 436 | 669 | 544 | 378 | 325 | 288 | 128 |
“
Additional information
| Weight | 92 kg |
|---|
