Description
Stovax Vogue Small Wood Burning Stoves
An excellent choice for smaller fireplaces or living spaces, the Stovax Vogue Small wood burning stove provides an ample 5kW of heat despite being the most compact model in the range. Presenting a stunning view of the flames, Vogue models feature a signature bevelled cast iron door with an expansive glass viewing window, kept clear by the powerful Airwash system that also aids the range’s high levels of combustion efficiency.
Key Features
- Ecodesign Plus
- Efficiency: 80.7%
- Nominal Heat Output and Range: 5kW (2 – 7kW)
- Wood burning
- Approved for Smoke Control Areas
- Cleanburn & Airwash
- Integral cast iron top plate
- Optional external air kit
- Optional Midline wood store base
- Optional Plinth base
- Max Log Length: 280mm or 11
- Room vent not normally required
- Flue outlet: 5″ top or rear
- Stove bench compatible
Specifications
| Size |
Width |
Height |
Depth |
Energy Efficiency Class |
| Vogue Small |
371mm |
497mm |
334mm |
A+ |
| Vogue Small Plinth |
371mm |
547mm |
334mm |
A+ |
| Vogue Small with Optional Midline Base |
371mm |
693mm |
334mm |
A+ |
Dimension Diagram
| Model |
A |
B |
C |
D |
E |
F |
G |
H |
I |
J* |
K |
L |
M |
N ø |
| Vogue Small |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
“
