Description
Studio Edge + Inset Wood Burning Fire
As a continuation from the Stovax Studio Edge, the Ecodesign Edge + inset wood burning fire provides a similarly frameless ‘hole in the wall’ fire look, yet offers the additional benefit of a more simplified finishing process.
A slim profile decorative frame, crafted from 1mm thick steel, overlays the finished wall surface and provides a perfectly crisp finish around the installation opening.
With a complementary Matt Black finish, the Studio Edge + inset fire is a sophisticated and functional styling option that simply lets the Studio’s impressive wood burning flame picture provide all the aesthetic appeal!
Key Facts
| Specification | Details |
|---|---|
| Brand | Stovax |
| Ecodesign Plus | ✓ |
| High Efficiency | Up to 77.8% |
| Energy Efficiency Class | A |
| Boost Setting | ✓ |
| Flue Connection | 153mm (6 inches) top |
| Suitable for Smoke Control Areas* | ✓ |
Studio Edge + Sizes
| Model | Heat Output | Max Log Length | Frame Width (mm) | Frame Height (mm) | Efficiency |
|---|---|---|---|---|---|
| Studio 500 | 5.0kW | 250mm | 700 | 573 | 75.8% |
| Studio 1 | 5.0kW | 300mm | 785 | 463 | 77.8% |
| Studio 2 | 8.5kW | 400mm | 983 | 488 | 76.3% |
| Studio 3 | 12.6kW | 500mm | 1372 | 493 | 76.1% |
*Sizes 500, 1 and 2 only. When fitted with a Smoke Control Kit and used in accordance with the operating instructions.
