Description
Studio Edge Inset Wood Burning Fire
The Ecodesign Stovax Studio Edge inset fire is for those who require minimalist modern perfection. This contemporary wood burning fire has a seamless no-frame design, allowing your home’s interior to frame and enhance the roaring flames.
The Studio 500 has been specifically designed to fit into a standard 22 inches British fireplace opening without any additional building work.
Key Facts
| Specification | Details |
|---|---|
| Brand | Stovax |
| Ecodesign Plus | ✓ |
| High Efficiency | Up to 77.8% |
| Energy Efficiency Class | A |
| Boost Setting | ✓ |
| Flue Connection | 153mm (6 inches) top |
| Suitable for Smoke Control Areas* | ✓ |
Studio Edge Sizes
| Model | Heat Output | Max Log Length | Frame Width (mm) | Frame Height (mm) | Efficiency |
|---|---|---|---|---|---|
| Studio 500 | 5.0kW | 250mm | 550 | 421 | 75.8% |
| Studio 1 | 5.0kW | 300mm | 743 | 421 | 77.8% |
| Studio 2 | 8.5kW | 400mm | 943 | 446 | 76.3% |
| Studio 3 | 12.6kW | 500mm | 1330 | 451 | 76.1% |
*Sizes 500, 1 and 2 only. When fitted with a Smoke Control Kit and used in accordance with the operating instructions.
